The Wassi Group partnered with homeowner Gene Myers to convert hand-drawn sketches of a “forever home” into accurate, custom home plans and digital documentation.
TWG developed a coordinated 3D model and residential drawing set that clearly communicated the design to builders. Together, these documents provided a reliable foundation for confident planning and construction.
Client Goals
- Convert home sketches into construction drawings
- Confirm layout accuracy before construction
- Provide clear documentation for pricing and permits
- Visualize the design in a coordinated 3D model
TWG Approach
Our team translated the client’s sketches into a precise 3D Revit model, establishing accurate dimensions and architectural relationships. From this coordinated model, the team produced a complete residential drawing set, ensuring consistency across plans and reducing dimensional conflicts during construction.
Deliverables
- Parametric 3D Revit model of the residence
- Residential construction drawing set
- Coordinated sheets and documentation for builder use
Outcome & Value
By converting conceptual sketches into accurate digital custom home plans and building documentation, TWG provided the client and builder with a clear, dependable foundation for construction.
The coordinated 3D model improved visualization, reduced interpretation risk, and supported confident planning, pricing, and build execution for the Myers family’s custom home.
Planning a Custom Home?
Contact The Wassi Group to learn how our residential CAD drafting and Revit modeling services transform sketches into accurate, build-ready construction documentation.
